Campomatic C64BC - Manuale (Pagina 16)

6.2 + 3°C BLAST CHILLER CYCLE WITH CORE PROBE
The weight of the product must NEVER be more than 1 Kg.
The temperature reading takes place in the central part of the
product by inserting the core probe. Put the hot product into
the blast chiller, slide in the probe, ensuring that the tip is in
the centre of the product; to guarantee that the probe
works correctly in the blast chiller and deep-freezing
cycle, insert it as in the figure “inserting the probe”.
Close the door and press the reference button (button 1). The
display will show icons no. 7 and no. 9, which are lit at the
same time, indicating that the chosen cycle has started
correctly; icons no. 10 no. 11 and no. 12, which show the time
progression, will progressively switch off, flashing in order. At
the end of the cycle, icons no. 10, no. 11 and no. 12 will flash
together with a buzzer which will sound for around 20 seconds;
to end the cycle open the door.
6.3 -18°C STANDARD FOODS DEEP-FREEZING CYCLE WITH
CORE PROBE
The weight of the product must NEVER be more than 1 Kg.
The temperature reading takes place in the central part of the
product by inserting the core probe. Put the hot product into
the blast chiller, slide in the probe, ensuring that the tip is in
the centre of the product; to guarantee that the probe
works correctly in the blast chiller and deep-freezing
cycle, insert it as in the figure “inserting the probe”.
Close the door and press the reference button (button 2). The
display will show icons no. 8 and no. 9 which are lit at the
same time, indicating that the chosen cycle has started
correctly; icons no. 10, no. 11 and no. 12, which show the
time progression, will progressively switch off, flashing in
order. At the end of the cycle, icons no. 10, no. 11 and no. 12
will flash together with a buzzer which will sound for around 20
seconds; to end the cycle open the door.
12
