Funzionamento
4-22 HPR130XD Manual Gas – 806324 Revisione 2
Compensazione prevista per la larghezza dell’incisione
Le larghezze indicate nella tabella sotto riportata servono come riferimento. A causa delle differenze tra le varie installazioni
e della diversa composizione dei materiali, i valori ottenuti possono variare rispetto a quelli riportati nelle tabelle.
Nota: N/D = non disponibile
Metrico
Imperiale
Processo
Spessore (mm)
1,5 3 5 6 8 10 12 15 20 25 32 38
Acciaio al carbonio
130 A O
2
/ Aria N/D 1,64 1,77 1,81 1,92 2,04 2,11 2,22 2,65 3,43 4,26 4,59
80 A O
2
/ Aria N/D 1,37 1,53 1,73 1,79 1,91 2,00 2,11 2,72 N/D N/D N/D
50 A O
2
/ O
2
1,52 1,74 1,86 1,86 2,09 N/D N/D N/D N/D N/D N/D N/D
30 A O
2
/ O
2
1,35 1,45 1,54 1,56 N/D N/D N/D N/D N/D N/D N/D N/D
Acciaio inox
130 A H35 / N
2
N/D N/D N/D N/D 2,69 2,72 2,77 3,03 2,90 3,25 N/D N/D
130 A N
2
/ N
2
N/D N/D N/D 1,83 1,89 1,88 2,42 2,51 3,00 N/D N/D N/D
80 A F5 / N
2
N/D N/D 1,02 1,20 1,05 0,96 N/D N/D N/D N/D N/D N/D
45 A F5 / N
2
0,59 0,38 0,52 0,54 N/D N/D N/D N/D N/D N/D N/D N/D
45 A N
2
/ N
2
0,49 0,23 N/D N/D N/D N/D N/D N/D N/D N/D N/D N/D
Alluminio
130 A H35 / N
2
N/D N/D N/D N/D 2,70 2,72 2,77 2,36 2,90 1,72 N/D N/D
130 A Aria / Aria N/D N/D N/D 2,09 2,09 2,10 2,19 1,91 1,87 2,23 N/D N/D
45 A Aria / Aria 1,07 1,10 1,25 1,25 N/D N/D N/D N/D N/D N/D N/D N/D
Processo
Spessore (poll.)
0.060 0.135 1/4 5/16 3/8 1/2 5/8 3/4 1 1-1/4 1-1/2
Acciaio al carbonio
130 A O
2
/ Aria N/D 0.066 0.071 0.076 0.080 0.083 0.089 0.104 0.135 0.167 0.181
80 A O
2
/ Aria N/D 0.054 0.068 0.070 0.075 0.080 0.084 0.102 N/D N/D N/D
50 A O
2
/ O
2
0.060 0.063 0.073 0.082 N/D N/D N/D N/D N/D N/D N/D
30 A O
2
/ O
2
0.053 0.057 0.067 N/D N/D N/D N/D N/D N/D N/D N/D
Acciaio inox
130 A H35 / N
2
N/D N/D N/D 0.115 0.121 0.123 0.124 0.125 0.129 N/D N/D
130 A N
2
/ N
2
N/D N/D 0.072 0.074 0.083 0.095 0.100 0.118 N/D N/D N/D
80 A F5 / N
2
N/D 0.032 0.047 0.050 0.052 N/D N/D N/D N/D N/D N/D
45 A F5 / N
2
0.023 0.015 0.021 N/D N/D N/D N/D N/D N/D N/D N/D
45 A N
2
/ N
2
0.019 0.009 0.006 N/D N/D N/D N/D N/D N/D N/D N/D
Alluminio
130 A H35 / N
2
N/D N/D N/D 0.106 0.107 0.109 0.112 0.114 0.120 N/D
130 A Aria / Aria N/D N/D 0.082 0.082 0.082 0.086 0.071 0.071 0.089 N/D
45 A Aria / Aria 0.042 0.043 0.049 N/D N/D N/D N/D N/D N/D N/D
