6
and directly on the hi-fi system. (For further details see section
4.7.3 SOUND MENU ADJUSTEMENTS, under the options
“Preset”, “Hi-Fi” and “Hi-Fi Fixed”).
• Connectors for external speakers [R]
-These connectors pr ovide an OUTPUT from the television for
audio signals (amplified inside the television) to an external 3-
speaker kit you intend connecting to the television.
ATTENTION: The “Central” socket only accepts speakers with a
4 Ohm impedance while the “Rear” connectors will only accept
speakers with an 8 Ohm impedance.Since a wr ong connection
could damage the television’s inside device, check the impedance
of your speakers accurately and verify that the impedances of the
television connectors match.
• DB9 Serial Connector [T]
-This is a service connector and used only to update the television
control softwar e.
Updating may only be done by specialzed technical personnel
equipped with the necessary software.
T able 2
This table summarises the various
connection posssibilities between
the external appliances and the
connectors on the television.
EXTERNAL APPLIANCE SIGNAL TYPE CONNECTOR NAME CONNECTOR
Antenna RF Antenna [B]
Antenna, Composite Video Video [C] [D] [F]
Satellite or Cable (Analog or Digital) S-Video S-Video [E]
television receiver Component Video Component Video/RGBS [G][S]
RGB Component Video/RGBS [C]
DVD player Composite Video Video [C] [D] [F]
S-Video S-Video [E]
Component Video Component Video/RGBS [G][S]
RGB Component Video/RGBS [C]
Video r ecorder Composite Video Video [C] [D] [F]
S-Video S-Video [E]
Video camera Composite Video Video [C] [D] [F]
S-Video S-Video [E]
Video game console Composite Video Video [C] [D] [F]
S-Video S-Video [E]
Component Video Component Video/RGBS [G][S]
RGB Component Video/RGBS [C]
RGB Graphics RGB [H]
Computer RGB Graphics RGB [H]
