4�3 - STACKING PROCEDURE
Remove the central bar “A” from the flybar by pulling out the linchpins “X” and the quick lock pins “S”�
4�3�1 - STACKING ON SUB HL 35-S
Remove the central bar “A” from the flybar by pulling out the linchpins “X” and the quick lock pins “S”�
1� Secure the flybar to HL 35-S
2� Secure the stacking bar“B” (as shown in the picture) to the flybar using the quick lock pin “S” (follow the indication
“stacking point”)
1� Secure HL 6 to the flybar using the frontal quick lock pins “F1”�
A
S S
XX
5. INSTALLATION
B
S
P
F1
F1
