Multi-Contact MA259 - Manuale

Advanced Contact Technology
www.multi-contact.com 1 / 8
PV-KST3-P AU PV-KBT3-P AU
MA000 (de_en)
Montageanleitung MA000 (de_en)
Assembly instructions MA259 (it_en)
Istruzioni di montaggio MA259 (it_en)
Assembly instructions
Spina per test PV-KST3-P AU
Boccola per test PV-KBT3-P AU PV test plug PV-KST3-P AU
PV test socket PV-KBT3-P AU
Indice
Istruzioni per la sicurezza ............................................................2
Utensili di montaggio ................................................................3
Preparazione del cavo ................................................................3
Connessioni a crimpare .............................................................4
Crimpatura .................................................................................4
Montaggio .................................................................................5
Angolo di curvatura del cavo .....................................................6
Connessione ..............................................................................6 Content
Safety Instructions ......................................................................2
Tools required ............................................................................3
Cable preparation ......................................................................3
Crimp connections ....................................................................4
Crimping ....................................................................................4
Assembly ...................................................................................5
Cable routing .............................................................................6
Engagement ..............................................................................6
Spina per test / Test plug Boccola per test / Test socket
