Once the software update is complete, the inverter enters its startup phase before going
on to start feeding energy into the grid. The USB stick can be unplugged.
When the inverter software is updated, any custom settings that were configured in the
Setup menu are retained.
IMPORTANT! In order for the logging function to work correctly the time must be set cor-
rectly.
Relay Activate relay, relay settings, relay test
* these are only shown if the 'E-Manager' function has been activated under 'Relay mode'.
Relay mode
for selecting the different functions of the floating switch contact in the data communication
area:
-
Alarm function
- Active output
- Energy-Manager
Logging interval
Activate / deactivate the logging function and specify a logging interval
Unit Minutes
Setting range
30 min. / 20 min./ 15 min./ 10 min./ 5 min./ No log
Factory setting 30 min.
30 min. The logging interval is 30 minutes; every 30 minutes new log-
ging data will be saved on the USB stick.
20 min.
15 min.
10 min.
5 min.
The logging interval is 5 minutes; every 5 minutes new logging
data will be saved on the USB stick.
No log No data is saved
Setting range Relay mode / Relay test / Switch-on point* / Switch-off point*
Setting range ALL / Permanent / OFF / ON / E-Manager
Factory setting ALL
Alarm function:
Permanent /
ALL:
Switch the floating switch contact for permanent and temporary ser-
vice codes (e.g. brief interruption to energy being fed into the grid, a
service code occurs a certain number of times a day - can be adjusted
in 'BASIC' menu)
Active output:
ON:
The floating NO contact is on all the time the inverter is in operation
(as long as the display is not dark and is displaying something).
OFF: The floating NO contact is off.
