Fronius Symo x.x-3-S - Manuale (Pagina 18)

16
Fronius Datamanager 2.0
Controls, connec-
tions and dis-
plays on the
Fronius Dataman-
ager
No. Function
(1)
IP switch
For switching the IP address:
Switch position A
Specified IP address and opening of the WLAN Access Point
For a direct connection to a PC via LAN, the Fronius Datamanager 2.0 uses the
static IP address 169.254.0.180.
If the IP switch is in position A, an Access Point for a direct WLAN connector to
the Fronius Datamanager 2.0 is opened.
Access data for this Access Point:
Network name: FRONIUS_240.XXXXXX
Code: 12345678
Access to the Fronius Datamanager 2.0 is possible:
-
using the DNS name “http://datamanager”
- using the IP address 169.254.0.180 for the LAN interface
- using the IP address 192.168.250.181 for the WLAN Access Point
Switch position B
Assigned IP address
The Fronius Datamanager 2.0 uses an assigned IP address (factory setting dy-
namic (DHCP))
The IP address can be set on the Fronius Datamanager 2.0 website.
(5)
(1)
(6) (7) (10) (8) (9)
(4)
(2)
(3)
