General Checklist
Before starting your working session, make sure:
1. To wear properly your SmartCAM Lite Vest (or similar).
2. To preload properly the springs of your Arm X-1 in accordance to the procedure
described above
3. To check that the Sled is properly fastened and the electrical elements.
4. To check that the 5/8” pivot has been weel tightened.
5. To adjust your arm's tilt, lining it up as much parallel as possible to your body either
through the tilt action (right-left rotation, as explained above) and through the
fastening system located on your Vest (front-back rotation).
Maintenance
Do not use alcoholic solvents or detergents to clean your Arm X1. To clean metal
components, we recommend you to use a paper towel lightly soaked in distilled water.
Joints are completely sealed: therefore do not lubricate any moving motion parts.
The spring lodging is protected against dust and dirt.
MATERIALS
Arm X1 is made with the following materials (in various percentages) :
· Aluminium 7075
· Carbon Fibre
· Steel C40 / Steel FE360B / AISI314
· Bronze
Materials and treatments to which the materials have been submitted for fabrication are
compatible with the current ROHS directive.
Disposal
Dispose of Your Arm X1 in accordance with current regulations. Address to special
