30
8. CONTENTS OF THE PACKAGE
AMI54Z
Power supply cable
Wire antenna
User manual
9. TECHNICAL FEATURE
Model AMIX54Z
INPUT CH1~CH5
Phantom power +48 V DC
MIC/Line XLR input Electronically Balanced
Gain -20 dB to -41dB
Max. Input -1.5/-22.5dBu (line/mic)
S/N ≥80dB
Sensitivity -18dBu
RCA Line Input Stereo unbalanced
Line Max. Input -4.5dBu
S/N ≥75 dB
Line Input Unbalanced
Sensitivity -21 dBu
Frequency Response 20Hz-22KHz +/-3dB
T.H.D. ≤0,03% @ 1KHz
Input Impedance 2.2 KOhm Micro
22 KOhm Line
Output Impedance 120 Ohm
Power supply 230VCA 50/60Hz
117VCA 50/60Hz
Power Consumption 14W
Input Connectors CH1~CH5: COMBO (XLR + JACK 6,3)
CH1~CH5: 2xRCA
Output Connectors XLR Male
Dimensions (WxHxD) 483x44.4x200 mm
1U Rack standard 19”
Weight 3.4Kg
The product complies with Directive 2004/108/EC (Electromagnetic Compatibility)
The product complies with Directive 2006/95/EC (Low Voltage)
Proel SpA is committed to a constant research and development policy and therefore reserves the right to change and improve its products at any
time without notice . REV.00 47/14
