GB
G27 cat.2Lw
Nominal heat input (kW) 15,2
Injector diameter (1/100mm) 155
Number of injectors 4
Pressure (mbar) 20
Maximum consumption (l/h) 1766
Primary air regulation (mm) X see fig. page 70 1
G2.350 cat.2Ls
Nominal heat input (kW) 15,2
Injector diameter (1/100mm) 194
Number of injectors 4
Pressure (mbar) 13
Maximum consumption (l/h) 2011
Primary air regulation (mm) X see fig. page 70 1
G30 /G31 cat. I3+
Nominal heat input (kW) 15,2
Injector diameter (1/100mm) 94
Number of injectors 4
Pressure (mbar) 28..30/30..37
Maximum consumption (l/h) 1106
Primary air regulation (mm)
X
see fig. page 70 All open
G30 /G31 cat. I3B/P (30)
Nominal heat input (kW) 15,2
Injector diameter (1/100mm) 94
Number of injectors 4
Pressure (mbar) 30
Maximum consumption (l/h) 1106
Primary air regulation (mm)
X
see fig. page 70 All open
G30 /G31 cat. I3B/P (37)
Nominal heat input (kW) 15,2
Injector diameter (1/100mm) 89
Number of injectors 4
Pressure (mbar) 37
Maximum consumption (l/h) 1106
Primary air regulation (mm) X see fig. page 70 All open
