23
Channel B setting (Similarly for Channel D):
After having pressed SET key (fig.1, ref.5) ( the operating frequency will start lighting up ), press
contemporaneously SET and arrow “down” (fig.1, ref.5) to pass to band B.
Vice versa from band B: after having pressed one time SET key (fig.1, ref.5) ( the operating frequency will start
lighting up), press contemporaneously SET and Arrow “up” (fig.1, ref.5) to pass to Band A
At this point the operating frequency of band B will start lighting up:
Repeat the same operations as here above described in order to program Band A. Make sure that IR
transmission process will start pressing one time Arrow Key “down” (fig.1, ref.5) and the automatic programming
process scan will start pressing for 2 seconds Arrow key “down” (fig.1, ref.5)
List of compatible frequencies for multi-channel systems:
CANALE
KIT
CH A CH B CH C CH D
KIT a
GP 1
611.25 MHz
634.50 MHz 641.00 MHz 659.25 MHz
GP 2
612.75 MHz 636.75 MHz 647.50 MHz 668.75 MHz
GP 3
619.75 MHz 639.25 MHz 650.25 MHz 669.50 MHz
KIT b
GP 1
730.50 MHz 745.75 MHz 772.00 MHz 789.75 MHz
GP 2
742.75 MHz 751.00 MHz 760.25 MHz 782.00 MHz
GP 3
733.75 MHz 756.50 MHz 773.50 MHz 778.50 MHz
7. BATTERY RECHARGE PROCESS
Pull out the 2 batteries from the battery compartment set in the rear side of the microphone stand (fig.3, ref.10).
Insert the battery into the battery charger contained into the supply package.
Power on the battery charger.
When the red LED indicator turns green the batteries are fully charged .
Charging time is about 4-5 hours.
