Proel FREE10 - Manuale (Pagina 20)

20
FREE10 ‐ TECHNICAL SPECIFICATION
Wireless System
Modulation Mode
FM
Frequency Range UHF: 863‐865 MHz
Frequency Stability ±0.0005% ‐75 dB
Sensitivity ‐95 dBm
Adjacent Channel Rejection S/N > 40 dB
AF Output 80 dB
Distortion < 85 dB
Wireless Receiver FR1R
Handheld Transmitter FR1H
Bodypack Transmitter FR1B (optional)
Headset Microphone HS1 (optional)
Amplifier System
Speaker
1" horn loaded compression driver, 10" woofer
Continuous Power 100 W
Program Power 180 W
Distortion 1% ( at 10W )
Frequency Response 50Hz ‐ 18KHz, ‐3dB
Disc Unit CD/DVD/MP3 player with USB port
Inputs MIC IN 1&2 (XLR‐F), AUX IN 1 (1/4" JACK), AUX
IN 2 (MINIJACK, 2xRCA)
Outputs LINE OUT (1/4" JACK, 2xRCA), VIDEO OUT
(RCA), EXTERNAL SPEAKER (1/4" JACK)
Controls MIC 1&2 LEVEL, AUX 1&2 LEVEL, MP3 / DISC
LEVEL, ECHO, HIGH, LOW, MASTER, VOICE
PRIORITY, MUTE
Recharge Battery 2x 12 V / 7 Ah
Recharging Time 10‐12 hours
Working Time 3‐4 hours
Power Supply Selectable 115/230V AC input (±10%) 50/60 Hz,
Auxiliary 12‐24V DC input
Consumption 150W max
Dimensions (W x H x D) 34 x 52 x 38 cm
Weight 19.5 Kg (42.9 lb)
