FR1H is the UHF wireless microphone handheld
transmitter.
11
31. MICROPHONE GRILLE
This grid protects the microphone capsule and
includes a pop filter. The microphone uses a
dynamic capsule with a cardioid unidirectional
figure.
32. LOW BAT RED LED
This LED shows the battery status:
• When the microphone is switched ON, the
LED will light for about 1 second.
• If the batteries are charged, the LED will turn
off (even if the microphone is switched on
and operative).
• The LED will light again if the batteries are
near to be exhaust to indicate that they must
be replaced as soon as possible.
33. ON/OFF
ON/OFF switch.
34. MICROPHONE BODY In
order to open the microphone case and to
access the batteries compartment, just push the
red cap with a finger and use the other hand to
slide the microphone body down.
35. BATTERIES COMPARTMENT AND FREQUENCY
The microphone is powered by 2 type AA
alkaline batteries.
NOTE: the microphone is able to operate also
with 2 Ni‐MH rechargeable batteries, but in this
case the operating time is less.
A
sticker in the battery compartment shows the
transmitter frequency.
