12
INSTRUCTIONS FOR USE
Turning on the device
Turn the appliance on using the main switch “N”
(Fig. 4 - refer to the figure at the end of the
manual). The buttons of the keypad will light up
for about 3 seconds to verify proper operation of
all signals. At the end of this phase, leds T5 and
T6 will start flashing until the boiler has reached
the optimal temperature for dispensing of coffee.
Extract the machine from the cabinet by sliding it
all the way out on the guides.
Take the intake pipe out of the water tub. It has a
softener filter on the end which needs to be
changed every two thousand servings.
Take the tub out of the compartment and fill it with
2 l of water.
Attention: always take the tub out of its
housing to fill it.
Pout coffee beans into container “A” located
above the machine.
Push the machine into the cabinet.
Now, with water present, the machine is ready to
dispense coffee.
Preparation of coffee servings
To dispense coffee
Place the cup under the dispensing spouts and
briefly press the key T5 to start dispensing coffee.
Press the key T5 again to stop dispensing once
the correct serving size has been reached.
If the machine is programmed, it stopped
automatically.
To dispense steam
The machine can dispense steam for the
preparation of tea, cappuccino, or any other hot
beverage. To obtain steam, start the boiler by
pressing key “T3 start steam boiler” . The LED will
start flashing for about one minute, then it will stay
on steady to show that the boiler is ready to
dispense. One press of the key “T4 steam”
activates the dispensing solenoid valve and pump.
Pressing the key “T4 steam” again turns off the
solenoid valve.
The boiler goes off after about 10 minutes.
To turn off the boiler, press the key “T3 steam
boiler start” again. The LED and the boiler will
switch off.
ITAL
IANO
User programming
Adjustment of grinding:
by means of knob “B” which is found on the back
side of the machine. Turn it clockwise for finer,
stronger coffee. Turn it counter-clockwise for
coarser, weaker coffee.
Programming type of coffee (long or short):
it is possible to modify the amount of water using
keys T7 and T8, obtaining either a long or short
coffee.
The following table summarizes the flow rates:
Table 1 - Coffee types
T7 T8 Flow rate
Coffee
types
Minimum Very short
Medium Medium
Maximum Long
The value set each time the machine is turned on
is the maximum.
If water runs out during dispensing, the cycle is
interrupted immediately.
User programming
The machine is programmed for home use only
with medium coffee roaster
Programming coffee dispensing
press the key T1 for 5 seconds.
Select coffee types to programming with T7 and
T8 keys (table 1).
Press the key T5 and dispense coffee.
Press the key T5 again to stop dispensing.
Repeat the operation for all coffee types (table 1).
Press key T1 to exit and save.
Adjustment of grinding time
press the key T2 for 5 seconds.
Select grinding time with T7 and T8 keys
(following table).
T7 T8 Grinding time
Minimum
Medium
Maximum
Press key T2 to exit and save.
