ITEM DESCRIPTION
UM
QUANTITY
CODE
1
BASAMENT STOVE
NR
1
415301
2
BODY STOVE
NR
1
415300
3
DOOR HINGE (BODY)
NR
2
415302
4
DOOR HINGE (DOOR)
NR
2
415303
5
INTERNAL FRAME DOOR
NR
1
415304
6
HANDLE SUPPORT
NR
1
415305
7
HANDLE
NR
1
415306
8
EXTERNAL FRAME DOOR
NR
1
415307
9
BRACKET HOOK HOLDER
NR
1
415308
10
LOOK DOOR
NR
1
415309
11
DUCK BRACKET
NR
1
415310
12
PIPE PELLET FALL
NR
1
415311
13
SEAL PIPE PELLET FALL
NR
1
415312
14
REAR PLUG
NR
1
415313
15
PIPE PELLET FEED
NR
1
415314
16
PELLET TANK
NR
1
415315
17
LEFT INTERNAL PANEL
NR
1
415316
18
RIGHT INTERNAL PANEL
NR
1
415317
19
TOP PANEL
NR
1
415318
20
LEFT SIDE PANEL FOR DIANDRA 90
NR
1
415319
21
RIGHT SIDE PANEL FOR DIANDRA 90
NR
1
415320
22
LOWER PANEL DOOR FOR DIANDRA 90
NR
1
415321
23
BUSHING FOR AUGER
NR
2
410065
24
AUGER
NR
1
415322
25
HOLDING AUGER
NR
1
410056
26
AUGER SUPPORT
NR
1
415323
27
GEAR MOTOR MEM390 230/50/2RPM
NR
1
410006
28
CORNER SMOKE EXTRACTOR
NR
1
415324
29
POWER SUPPLY
NR
1
410011
30
SWITCH SUPPORT
NR
1
415325
31
REAR LOWER PANEL FOR DIANDRA 90
NR
1
415326
32
INSIEDE BLACK PLUG
NR
1
415327
33
THERMOSTAT 100¡ C LS16025516 2.5A T85
NR
1
410009
34
AIR GRILLE
NR
1
415328
35
TOP FOR DIANDRA 90
NR
1
415329
36
PELLET DOOR
NR
1
415330
37
TUBE ELETRIC HEATER
NR
1
415331
38
AUCTION SCRAPING
NR
1
415332
39
DUCT SUPPORT PANEL
NR
1
415333
40
UPPER REAR PANEL
NR
1
415334
41
REAR FLAME SHIELD
NR
1
415335
42
SMOKE AROUND REAR
NR
1
415336
43
SMOKE AROUND RIHT SIDE
NR
1
415337
44
SMOKE AROUND LEFT SIDE
NR
1
415338
45
RIGHT LOCKING BRACKET
NR
1
415339
46
LEFT LOCKING BRACKET
NR
1
415340
47
RIGHT FLAME SHIELD
NR
1
415341
48
LEFT FLAME SHIELD
NR
1
415342
49
FLAME SHIELD
NR
1
415343
50
BURNER
NR
1
415344
51
GLASS
NR
1
415200
52
DEFLECTOR FOR DUCTING
NR
1
415345
53
SENSOR SUPPORT
NR
1
410099
54
ELECTRIC HEATER 270W 230V X 6-8KW
NR
1
410010H
55
CONNECTION FLANGE DUCT
NR
2
415346
71
CENTRIFUGAL FAN
NR
1
411188N
72
SMOKE EXTRACTOR PL21CE0180
NR
1
415346
75
PIN HOLE FOR DEFLECTOR
NR
1
415347
76
PIN FOR DEFLECOTR
NR
1
415348
77
ASH BOX
NR
1
415349
78
DIFFERENTIAL AIR PRESSURE SWITCH
C6065A1002:2 0,6-6MBAR
NR
1
410007
79
ADJUSTABLE FEET
NR
4
410023
80
PCB J042
NR
1
411300
82
AUCTION FOR DUCT
NR
1
415349
¯
DISPLAY
NR
1
411300
¯
DOOR SEAL DIAM 14MM
ML
1
410020
¯
GLASS SEAL 15X3MM
ML
1
410029
¯
FLAT CABLE FOR DISPLAYER
NR
1
410238
¯
CABLING
NR
1
420005
¯
REMOTE CONTROL
NR
1
410673
¯
ROOM SENSOR STUFA
NR
1
410240
¯
USER MANUAL
NR
1
001170
¯
INSTALLATION MANUAL
NR
1
001171
¯ particolare non rappresentato nell'esploso.
