16
Thank you for choosing this Proel product and for trusting our brand, which strives to be synonymous with
professionalism, precision, high quality and reliability. All of our products comply with EC regulations regarding audio
equipment for continuous use.
2. DESCRIPTION
This device was specifically designed to mix microphone and music signals for sound reinforcement systems. It
features:
• High-quality design and manufacturing accuracy
• Six balanced COMBO mic/line inputs
• Three unbalanced RCA stereo line inputs
• Line/phantom mic/mic input selectors
• Input signal LED indicators for each channel
• Adjustable MIC 1 priority function
• Independent gain controls for channels 1-9
• Two balanced XLR outputs (Left and Right)
• Balanced mono output
• Stereo REC output (Left and Right), RCA type
• Output signal level LED indicators (Left and Right)
• MASTER volume control
• Tone controls
• Emergency power connectors (24 V DC)
Product complies with CE regulations
3. FRONT PANEL FUNCTIONS AND CONTROLS
fig.1
1. POWER
Main power switch
2. MIC/LINE IN LEVEL
Adjusts each mic/line input level
3. STEREO LINE IN LEVEL
Adjusts each stereo line input level
4. SIG
This LED indicates the presence of a signal
