5. Connect the audio line terminal cables to the ceramic terminal clamp,
paying attention to the polarity. Finish the installation placing the
speaker in the support ring and rotating it to the right for a firm and
secure mounting.
Technical Specifications
Model CS5TAL CS6TAL
Woofer 5,5” 6.5”
Input power max 12 W max 20 W
Output power 1,5 / 3 / 6 W 3 / 6 / 12 W
100V: 6.6 / 3,3 / 1,66 KΩ 100V: 3.33KΩ/1.66KΩ/833Ω
70V: 3,3 KΩ / 1,66 KΩ / 816Ω 70V: 1.66KΩ/833Ω/ 408Ω/
Input impedance
50V: 1,66 KΩ / 816Ω / 416Ω 50V: 833Ω/408Ω/208Ω
Input voltage 50/70/100 V 50/70/100 V
Frequency response 140 Hz-20 KHz 100 Hz-20 KHz
S.P.L. 89 dB(1W/m) 90 dB(1W/m)
Dimension (mm) Ø 180 – H 109 Ø 220 – H 150
Weight (Kg) 1,4 1,6
Proel S.p.A. pursues a policy of constant research and development and therefore reserves the right to
improve its products at any time without prior notification.
