FR1H is the UHF wireless microphone handheld transmitter.
21. MICROPHONE GRILLE
This grid protects the microphone capsule and includes a pop
filter. The microphone uses a dynamic capsule with a cardioid
unidirectional figure.
22. LOW BAT RED LED
This LED shows the battery status:
• When the microphone is switched ON, the LED will light for
about 1 second.
• If the batteries are charged, the LED will turn off (even if
the microphone is switched on and operative).
• The LED will light again if the batteries are near to be
exhaust to indicate that they must be replaced as soon as
possible.
23. ON/OFF
ON/OFF switch.
24. MICROPHONE BODY
In order to open the microphone case and to access the
batteries compartment, just push the red cap with a finger and
use the other hand to slide the microphone body down.
25. BATTERIES COMPARTMENT AND FREQUENCY
The microphone is powered by 2 type AA alkaline batteries.
NOTE: the microphone is able to operate also with 2 Ni‐MH
rechargeable batteries, but in this case the operating time is
less.
A sticker in the battery compartment shows the transmitter
frequency.
