FR1B is the UHF wireless bodypack transmitter.
26. AUDIO INPUT
3,5mm mini jack input socket to connect the supplied
headset microphone.
27. ON
GREEN LED that shows the “ON” status of the
bodypack.
28. LOW BAT
RED LED that shows the battery status: the LED will
light if the batteries are near to be exhaust, to indicate
that they must be replaced as soon as possible.
29. ON/OFF and LEVEL CONTROL
This potentiometer is used for switching ON the
bodypack and for adjusting the level of the
microphone.
30. BATTERY COMPARTMENT
Sliding down the lower part of the bodypack you can
access to the battery compartment.
To operate the microphone needs 2 type AA alkaline
batteries.
NOTE: the microphone is able to operate also with 2
Ni‐MH rechargeable batteries, but in this case the
operating time is less.
31. CLIP
Clip for hooking the bodypack to the belt.
32. FREQUENCY
On the back side of bodypack a sticker shows the
operating frequency of the transmitter.
