7. Technical specifications
Model
AMP30 AMP60 AMP120
RMS / MAX (W) output
power
30/45 60/90 120/180
Constant voltage outputs 25,70,100V
Constant impedance output 4 Ω
Inputs connectors
INPUT 1~ INPUT 4: XLR connectors,
AUX INPUT: RCA
MAIN-IN: on terminal board
Outputs connectors
4Ω: on terminal board
25, 70, 100V: on terminal board
PRE OUT on terminal board
TAPE OUT RCA
Frequency response 50-15.000 Hz (±3 dB)
Harmonic distortion ≤ 1% (1Khz @ rated output power)
Signal to noise ratio INPUT 1-4: ≥55 dB; AUX INPUT: ≥55 dB; MAIN-IN: ≥55 dB;
Controls
5 volume independent control for each input – 1 MASTER output
volume control - 1 TREBLE control - 1 BASS control
Equalization BASS: ± 10 dB @ 100 Hz; TREBLE: ±10 dB @ 10 KHz
24V Phantom power
(defeatable)
Inputs 1, 2, 3, 4
AC power 115/230 V AC (±5%) – 50/60 Hz
DC power 24V
AC power consumption 90W 180W 360W
DC power consumption 6.3 A 8 A 10 A
Rack unities 2U standard 19”
Dimensions (W x H x D) 420 mm. x 88 mm. x 280 mm. – 16.5 in. x 3.5 in. x 11 in.
Weight 6.9 Kg. - 15.1 lbs 7.8 Kg. - 17.2 lbs 10 Kg. - 22 lbs
