Proel AUP4125S Manuale d'uso
Pagina 26
26
7. TECHNICAL FEATURE
The product complies with Directive 2004/108/EC (Electromagnetic Compatibility)
The product complies with Directive 2006/95/EC (Low Voltage)
8. CONTENTS OF THE PACKAGE
Amplifier
Network power supply cable
Operating Manual
Model:
AUP4125S
AUP4250S
Output power RMS
4 x 125W
4 x 250W
Inputs
4 X balanced line
4 X Priority unbalanced line
4 X balanced line
4 X Priority unbalanced line
Input Sensitivity
Line: 1V/47kΩ ‐ variable gain 600Ω
Line: 1V/47kΩ ‐ variable gain 600Ω
Controls
4 Master volume controls
4 treble tone controls
4 bass tone controls
4 Master volume controls
4 treble tone controls,
4 bass tone controls
Loudspeakers outputs
100/70V/4Ω
100/70V/4Ω
Frequency response
20Hz ‐20khz (‐3dB)
20Hz ‐20khz (‐3dB)
Distortion (THD)
< 0.5% (@ Pnom 1KHz)
< 0.5% (@ Pnom 1KHz)
S/N Ratio
≥90dB
≥90dB
Power Supply
230/117Vac 50/60Hz
230/117Vac 50/60Hz
Operating temperature
0 ‐40°C
0 ‐40°C
Input/Output Connectors
screw terminals/terminal block
screw terminals/terminal block
Power Consumption
1000VA
2000W
Dimensions (LxHxP) (mm)
434x88.5x425 – 2 rack units 19”
434x88.5x425 – 2 rack units 19”
Weight (Kg)
9.75Kg (21.5lb)
10.35Kg (22.82 lb)
Proel SpA is committed to a constant research and development policy and therefore reserves the right to change and improve its products at any
time without notice . REV.00 19/14
