18

To view manuals, videos, drivers, downloads, technical drawings, and more visit www.startech.com/support

Installing the Side Panels

Note:

At least two people are required when removing or

reinstalling the

Side Panel

.

1.

While supporting the weight of the

Side Panel

align the

bottom lip of the

Side Panel

with the lip on the

Rack’s

Frame

.

2.

Slide the lip of the

Side Panel

into the lip on the

Rack’s

Frame

.

3.

Push the top of the

Side Panel

into the

Rack’s Frame

until

you hear it click (lock) into place.

Grounding the Rack

1.

Insert an

M6 Screw

through the grounding point on the

Grounding Wire

(sold separately) and into the

Ground

Hole

, located on the bottom of the

Rack

just inside of either

the front or rear

Door Frame

.

2.

Run the

Grounding Wire

under the

Rack’s Frame

to prevent

obstructing the

Rack Door

from closing.

3.

Connect the

Grounding Wire

to an earth ground

connection.
