Select the bank to be copied via the BANK UP/DOWN buttons

Press MIDI/REC button to prepare saving

Select the bank where you want to copy the bank, via the BANK UP/DOWN buttons

Press the MUSIC/BANK COPY button to copy the bank. All leds on the panel will flash.

CHASE

A chase is a sequence of different programs (banks) that will be called up one after another. With the DMX operator, you can

program up to . different chases each up to steps.

PROGRAMMING A CHASE

Press and hold the PROGRAM button for about 2 seconds to enter the programming mode. The program flash will flash.

Select the chaser to be programmed via the CHASE buttons

Select the desired program via the BANK UP/DOWN button

Select the desired scene via the SCENE buttons

Press the MIDI/REC button

Program the next steps until the chase is finished or the maximum number of steps (240) has been reached

Press and hold the PROGRAM button in order to save the chase

RUNNING A CHASE:

Press the respective CHASE button and press the AUTO button.

You can ad just the chase speed by tapping the DISPLAY button twice. The time interval between the 2 taps correspond

to the chase speed (up to 10 minutes)..

CHECKING A CHASER:

Press and hold the program button and select the desired chase via the CHASE button.

Press the DISPLAY button in order to switch the display to step.

Check every scene individually by pressing the respective BANK UP/DOWN button.

EDITING A CHASER:

Copy a bank into a chase

Press and hold the PROGRAM button for about 2 seconds to enter the programming mode. The program flash will flash.

Select the desired chase via the CHASE button. The respective led will be lit.

Select the bank to be copied vie BANK UP/DOWN buttons

Press the MUSIC/BANK COPY button to prepare copying

Press MIDI/REC button to copy the bank. All leds on the panel will flash.

Copy a scene into a chase

Press and hold the PROGRAM button for about 2 seconds to enter the programming mode. The program flash will flash.

Select the desired chase via the CHASE button. The respective led will be lit.

Select the bank in which the scene will be copied vie BANK UP/DOWN buttons

Select the scene you want to copy via SCENES button

Press MIDI/REC button to copy the scene. All leds on the panel will flash.

Inserting a scene in a chaser

Press and hold the PROGRAM button for about 2 seconds to enter the programming mode. The program flash will flash.

Select the chase in wich a scene will be inserted via BANK UP/DOWN buttons. The respective led will be lit.

Press the DISPLAY button in order to switch the display to step.

Select a scene where a new scene is to be inserted, via BANK UP/DOWN buttons. Now the displaywill show the scene.

E.g. if you want to insert a scene between scene 5 and scene 6, press the BANK UP/DOWN buttons so that the display

show STEP05.

Press MIDI/REC to prepare inserting. Now the display will show the next scene.

Select the bank where the scene to be inserted via BANK UP/DOWN buttons

Select the scene to be inserted via the SCENES buttons

Press MIDI/REC button to insert the scene. All leds on the panel will flash.

Deleting a scene in a chase:

Press and hold the PROGRAM button for about 2 seconds to enter the programming mode. The program flash will flash.

Select the chase in which a scene will be deleted via the CHASE buttons

Press the DISPLAY button in order to switch the display to step.

Select the scene to be deleted via the BANK UP/DOWN buttons

Press AUTO/DEL button to delete the scene All leds on the panel will flash.

DELETE A CHASE:

Press and hold the PROGRAM button for about 2 seconds to enter the programming mode. The program flash will flash.

Select the chase to be deleted via CHASE buttons

Press and hold AUTO/DEL button and the respective chaser button to delete the chase. All leds on the panel will flash.

DELETE ALL CHASE:

Caution: when you select this function, all program chase will irrevocably be lost. The individual scenes and programs are

maintained

Switch off the device

Press and hold the BANK DOWN + DEL buttons, while switching on the device. All leds on the panel will flash.
