Proel SW118P Manuale d'uso
Pagina 7
7
SW118P - INPUT PANEL (FIG.1)
SW118P - PANNELLO INGRESSO (FIG.1)
PASSIVE - CONNECTIONS (FIG.2)
PASSIVO - CONNESSIONI (FIG.2)
PASSIVE - CONFIGURATION EXAMPLE (FIG.3) PASSIVO - ESEMPI CONFIGURAZIONI (FIG.3)
POWER OUTPUT - uscite altoparlanti
Connettore per cavo tipo Speakon Neutrik NL4
PROEL code - NL4FX
Codice PROEL - NL4FX
SPEAKER POWER OUTPUTS
Neutrik NL4 Speakon Cable Connector
2-
1+
2+
1-
20mm
0.8"
8mm
0.3"
RED
BLACK
positive / red / rosso
n.c.
1+
negative / black / nero
1-
n.c.
power amplifier 1000 W max (4 Ω)
or 500 W (8 Ω)
PROEL suggested model:
HPX2400
stereo mode: 2x 800W (4 Ω)
or 2x 450W (8 Ω)
PROEL suggested models:
4 channels HPD models
set as BI-AMP/PAR mode
( internal 100Hz crossover
HPD2004: 4x 250W (8 Ω)
HPD4004: 4x 500W (8 Ω)
LEFT
full range speaker
RIGHT
full range speaker
LEFT
SW118P subwoofer speaker
RIGHT
SW118P subwoofer speaker
SW118P (8 ohm)
to other 2x SW118P
SW118P (8 ohm)
sub ARRAY
SUB+SAT system
LOW
HIGH
L
2
1
R
R
L
PROTECT
BRIDGE
ON
LIMIT
SIGNAL
PROTECT
LIMIT
SIGNAL
