3
INDEX
TECHNICAL SPECIFICATIONS . . . . . . . . . . . . . . . . . 3
FREQUENCY RESPONSE . . . . . . . . . . . . . . . . . . . . . 4
DIMENSIONS AND FLYING POINTS . . . . . . . . . . . . . 4
ACCESSORIES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
CONNECTIONS (FIG.1) . . . . . . . . . . . . . . . . . . . . . . 6
CONTROL PANEL (FIG.2) . . . . . . . . . . . . . . . . . . . . . 6
CONFIGURATIONS (FIG.3) . . . . . . . . . . . . . . . . . . . 7
SAFETY AND PRECAUTIONS . . . . . . . . . . . . . . . . . . 8
IN CASE OF FAULT . . . . . . . . . . . . . . . . . . . . . . . . . . 8
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . 8
CE CONFORMITY . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
PACKAGING, SHIPPING AND COMPLAINT . . . . . . . 9
WARRANTY AND PRODUCTS RETURN . . . . . . . . . . 9
INSTALLATION AND DISCLAIMER . . . . . . . . . . . . . . 9
POWER SUPPLY AND MAINTENANCE . . . . . . . . . . 9
GENERAL INFORMATION . . . . . . . . . . . . . . . . . . . 10
INSTRUCTIONS (FIG. 1 / 2 / 3) . . . . . . . . . . . . . . . 10
INDICE
SPECIFICHE TECNICHE . . . . . . . . . . . . . . . . . . . . . . 3
RISPOSTA IN FREQUENZA . . . . . . . . . . . . . . . . . . . . 4
DIMENSIONI E PUNTI DI SOSPENSIONE. . . . . . . . . 4
ACCESSORI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
CONNESSIONI (FIG.1) . . . . . . . . . . . . . . . . . . . . . . . 6
PANNELLO DI CONTROLLO (FIG.2) . . . . . . . . . . . . . 6
CONFIGURAZIONI (FIG.3) . . . . . . . . . . . . . . . . . . . . 7
AVVERTENZE PER LA SICUREZZA . . . . . . . . . . . . . 12
IN CASO DI GUASTO . . . . . . . . . . . . . . . . . . . . . . . 12
PROBLEMATICHE COMUNI . . . . . . . . . . . . . . . . . . 12
CONFORMITÀ CE . . . . . . . . . . . . . . . . . . . . . . . . . . 13
IMBALLAGGIO, TRASPORTO E RECLAMI . . . . . . . 13
GARANZIE E RESI . . . . . . . . . . . . . . . . . . . . . . . . . 13
INSTALLAZIONE E LIMITAZIONI D’USO . . . . . . . . . 13
ALIMENTAZIONE E MANUTENZIONE . . . . . . . . . . 13
INFORMAZIONI GENERALI . . . . . . . . . . . . . . . . . . 14
ISTRUZIONI (FIG. 1 / 2 / 3) . . . . . . . . . . . . . . . . . . 14
MODEL V8A MODELLO V8A
System type 2-way vented enclosure Sistema 2-way vented enclosure
High Frequency Device 1’’ neodymium compression driver Altoparlante al 1’’ neodymium compression driver
Low Frequency Device 8” woofer with 1.5"VC Altoparlante bassi 8” woofer - 1.5"VC
Angular Coverage 90° H x 60° V Copertura angolare 90° H x 60° V
Total peak power 400 W Potenza massima di picco 400 W
HF Amplifi er Cont. Power 50 W Class D Potenza Con nua Amp. Al 50 W Classe D
LF Amplifi er Cont. Power 150 W Class D Potenza Con nua Amp. Bassi 150 W Classe D
Power Supply type SMPS Tipo alimentazione SMPS
Frequency Response 70 Hz - 20 kHz Risposta in Frequenza 70 Hz - 20 kHz
Processing Analog Processamento Analogico
Max SPL at 1mt (peak) 121 dBspl SPL max a 1m (picco) 121 dBspl
Crossover Frequency 2000 Hz Frequenza Crossover 2000 Hz
Input Impedance 30 kohm balanced
15 kohm unbalanced Impedenza ingresso 30 kohm bilanciato
15 kohm sbilanciato
Input Sensi vity LINE: +4 dBu / MIC: -20 dBu Sensibilità ingresso LINE: +4 dBu / MIC: -20 dBu
Controls MIC/LINE selector, LEVEL, LOW EQ, HIGH
EQ, GND li , FRONT LED selector. Controlli sele ore MIC/LINE, LEVEL, LOW EQ,
HIGH EQ, GND li , sele ore FRONT LED.
Connectors MIC/LINE: Combo XLR-F / JACK
LINK: XLR-M Conne ori MIC/LINE: Combo XLR-F / JACK
LINK: XLR-M
Power Supply 230 V~ or 120 V~ - 50/60 Hz Tensione alim. di rete 230 V~ o 120 V~ - 50/60 Hz
Rated Consump on 150 W Consumo nominale 150 W
Construc on Polypropylene Costruzione Polipropilene
Cabinet Colour Black Colore Nero
Flying System 4 x M8 top/bo om Sistema di sospensione 4 x M8 top/bo om
Handles 1 x top Maniglie 1 x top
Moun ng Pole 1 x bo om Flangia per supporto 1 x bo om
Monitor taper 46° Inclinazione monitor 46°
Weight 7 Kg (15.4 lb) Peso 7 Kg
Dimensions (W x H x D) 280 x 422 x 252 mm Dimensioni (LxAxP) 280 x 422 x 252 mm
* Rated consump on is measured with pink noise with a crest factor of 12 dB,
this can be considered a standard music program. * Il consumo nominale è misurato con un rumore rosa con un fa ore di cresta
di 12 dB, considerato come un programma standard di musica.
TECHNICAL SPECIFICATIONS SPECIFICHE TECNICHE
