Note:
• A diagram of the correspondence colour/power is shown on
the back of the driver.
• In case more than one horn is used in the same place, take
care of the polarity in order to achieve the required sound
pressure level. In case of parallel connected horn speakers,
the polarity must be the same for all units. If the
configuration is serial, care should be taken regarding the
polarity as with batteries connected in series.
Technical Specifications
Model HD60T
Power 60W (max 120W)
Input Voltage 100 V
Impedance 170
Ω / 60W - 250Ω / 40W - 520Ω / 20W
Frequency Response 200Hz – 4,5KHz
S.P.L. (1W/m) 115 db
Frame Material Aluminium
Dimension (mm) Ø 110 - H 160
Weight (Kg) 2,15
Proel S.p.A. pursues a policy of constant research and development and therefore reserves the right to
improve its products at any time without prior notification.
