Technical Specifications
Installation HD60T
1. Tightly screw the unit onto the horn in a clockwise direction as shown.
2. Select the output power required by connecting the audio signal line to
the neutral (black) and the positive (coloured) terminals in
correspondence to the required power level:
Model HD35 HD60
Power 35 W (max 70W) 60 W (max 120W)
Impedance 16
Ω
16
Ω
Frequency Response 150 Hz – 6 KHz 150 Hz – 6 KHz
S.P.L. (1W/m) 110 db with horn 112 db with horn
Frame Material Aluminium Aluminium
Dimension (mm) Ø 106 - H 110 Ø 114 - H 112
Weight (Kg) 1,4 1,65
black neutral
orange 60W
red 40W
brown 20W
