Sottogruppo torcia per macchina rt80m -8 – Hypertherm RT80 Rev.1 Manuale d'uso
Pagina 40
MANUTENZIONE/LISTA DEI COMPONENTI
5-8
RT80 / RT80M
Manuale dell’operatore
1
Sottogruppo torcia per macchina RT80M
Codice
Riferimento
articolo
Descrizione
Quantità
087035*
RT80M Machine Torch Assembly with 25 ft (7.6 m) Lead
087036*
RT80M Machine Torch Assembly with 50 ft (15.2 m) Lead
1
128640
Torch Main Body Replacement Kit
1
2
027889
Retaining Clip
1
3
058519
O-ring
1
4
128639
Cap-off Sensor Replacement Kit
1
5
075571
Cap-off Sensor Screws
2
6
128521
Torch Head Repair Kit
1
7
128643
Torch Mounting Sleeve Replacement Kit
1
8
075618
Torch Mounting Screws
3
9
128710
Torch Positioning Sleeve
1
10
128827
25 ft (7.6 m) Torch Lead Replacement Kit
1
11
128828
50 ft (15.2 m) Torch Lead Replacement Kit
1
12
128826
RT80/RT80M Quick Disconnect Repair Kit
1
128645
Torch Mounting Kit (for reassembly after installation)
1
* Il sottogruppo include i seguenti ricambi torcia: (Per informazioni sui ricambi torcia vedere pagina 5-4).
120926
Electrode
1
120925
Swirl Ring
1
120928
Retaining Cap
1
120929
Shield
1
120927
Nozzle
1
