Settings
The setting of the connected battery position is completely Tool-Free and can be made
both in lengthwise and in rotary indexed way: there are several position that grant the
desired position to be mantained, independently from the batteries weight.
Connections
SmartPACK may host up to two V-Mount ® / V-LOK ® / V-Lock ® batteries.
Directly interfacing with the wiring of the Matrix Core is it possible to obtain the following
connections:
CAM A CAM B AUX A AUX B 12/24V
Camera at 12V from battery A ■ 12V
Camera at 12V from battery B ■ 12V
Camera at 12V from battery A+B ■ ■ 12V
Camera at 12V from battery A with
AUX at 12V from battery A
■ ■ 12V
Camera at 12V from battery A with
AUX at 12V from batteria B
■ ■ 12V
Camera at 12V from battery B with
AUX at 12V from battery A
■ ■ 12V
Camera at 12V from battery B with
AUX at 12V from battery B
■ ■ 12V
Camera at 12V from battery A+B
with AUX at 12V from battery A
■ ■ ■ 12V
Camera at 12V from battery A+B
with AUX at 12V from battery B
■ ■ ■ 12V
Camera at 12V from battery A+B
with AUX at 12V from battery A+B
■ ■ ■ ■ 12V
Camera at 24V (both batteries
installed)
■ ■ 24V
Camera at 24V (both batteries
installed) with AUX at 12V
■ ■ ■ * 24V
• At 24V, batteriy B can not power AUXes.
