11
5.2 DMX mode
1 channel mode
Channel Value
Function
1 000 – 255 Macro
3 channels mode
Channel Value
Function
1 000 – 255 Red
2 000 – 255 Green
3 000 – 255 Blue
4 channels mode
Channel Value
Function
1 000 – 255 Dimmer
2 000 – 255 Red
3 000 – 255 Green
4 000 – 255 Blue
7 channels mode
Channel Value
Function
1 000 – 255 Dimmer
2 000 – 255 Red
3 000 – 255 Green
4 000 – 255 Blue
5 000 – 255 Color macros
6 000 – 255 Color macros speed
7 000 – 255 Strobe
5.3 Master / Slave mode
In this mode, multiple units can be linked together as one system and run in sync.
• Use DMX cable to link all the units together from DMX OUT to DMX IN connector.
• One unit is to be set as Master and this Master unit needs to work under Auto, Sound or
manual mode. Other units are to be set in DMX mode.
•
Operate the Master unit in AUTO and Sound mode to run the whole system.
