2
INDICE:
ATTENZIONE………………………………………………………………… p. 3
INTRODUZIONE…………………………………………………………….. p. 3
NORME DI SICUREZZA……………………………………………………. p. 3
CONDIZIONI OPERATIVE…………………………………………………. p. 4
INSTALLAZIONE……………………………………………………………. p. 5
Installazione / sostituzione lampada…………………………………. p. 5
Regolazione della lampada…………………………………………… p. 6
Messa a fuoco…………………………………………………………. p. 7
Installazione sospesa……..…………………………………………... p. 7
Connessione alla rete di alimentazione……………………………… p. 8
MESSA IN FUNZIONE……………………………………………………… p. 8
PULIZIA E MANUTENZIONE………………………………………………. p. 8
CARATTERISTICHE TECNICHE………………………………………….. p. 9
TABLE OF CONTENTS:
CAUTION…..………………………………………………………………… p. 10
INTRODUCTION…………………………………………………………….. p. 10
SAFETY INSTRUCTIONS.…………………………………………………. p. 10
OPERATING DETERMINATIONS…………………………………………. p. 11
INSTALLATION………………………………………………………………. p. 12
Installing / replacing the lamp…………..……………………………. p. 12
Lamp adjustment………….…………………………………………… p. 13
Focusing.………………………………………………………………. p. 13
Overhead rigging……………..………………………………………... p. 13
Connection with the mains…………….……………………………… p. 14
OPERATION…………………………………………………………………. p. 14
CLEANING AND MAINTENANCE………………………………………… p. 15
TECHNICAL SPECIFICATION……………………………………………. p. 15
15
CLEANING AND MAINTENANCE
DANGER OF LIFE: disconnect from mains before starting cleaning and maintenance
operations.
We recommend a frequent cleaning of the device. Please use a moist, lint-free cloth.
Never use alcohol or solvents.
CAUTION: the lens has to be replaced when it is obviously damaged, so that its function
is impaired, e.g. due to cracks or deep scratches.
The objective lens will require weekly cleaning as smoke-fluid tends to building up
residues, reducing the light-output very quickly. The interior of the device should be
cleaned at least annually using a vacuum-cleaner or an air-jet.
There are no serviceable parts inside the device, except for the lamp. Maintenance and
service operations are only to be carried out by authorized dealers.
Please refer to the instructions under “Installing / Replacing the lamp”.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by
authorized dealers only in order to avoid hazards.
Should you have further question, please contact your dealer.
TECHNICAL SPECIFICATIONS
Power supply 230V / 50Hz
(117V / 60Hz USA)
Power consumption 590W
Dimensions (l x a x p) mm 650 x 180 x 260
Weight 6 kg
Lamp HPL 575W
Maximum ambient temperature 45 °C
Maximum housing temperature 245 °C
Please note: Every information is subject to change without prior notice.
