1. DESCRIPTION
Stereo volume attenuator for 4/8/16 Ω speakers, 12 positions, 2x50W maximum power handling , Box for flush mounting (model. 503 - not
include in the supply)
2. INSTALLATION
Connection:
1. Connect 4/8/16 Ω line signal -from the amplifier- to terminal IN respecting the polarities .
2. Connect the diffuser at 4/8/16 Ω to terminal OUT respecting the polarities.
Positioning
Screw the "fruit" of the housing 503 above the side wall Place the plate and screw.
The product is in compliance with Directive 2004/108/CE (Electromagnetic Compatibility)
it is also in compliance with Directive 2006/95/CE (Low Voltage)
Stereo volume attenuator
TR50ST
Proel SpA maintains a policy of constant research and development, therefore we reserve the right to apply improvements to existing equipment
without prior notice. REV. 00 07/14
