12
6. FM TUNER OPERATION
Specific functions of the pushbuttons/controls:
POWER
Switches the unit ON and OFF.
MEMORY
Press this button to activate memory mode. The LCD displays MEMO.
Press one of the memory buttons (from 1 to 10) to store the currently tuned radio station.
UP/DOWN
Press and hold these buttons for more than 0.5 seconds to enter automatic search mode.
If they are held pressed for less than 0.5 seconds, the radio stations will be searched manually.
7. TECHNICAL SPECIFICATIONS
8. TROUBLESHOOTING
Problem Possible solution
The display is not activated when the power
switch is ON. • Make sure that the unit is properly plugged in.
• Make sure the fuse is not blown.
No sound. • Make sure the cables are all connected correctly.
Intermittent audio output, audio buzz or
distorted audio. • Make sure the power supply has the correct voltage.
The CD display is off. • Make sure the CD power switch is ON.
No output signal from the CD. • Make sure the CD is clean and free from scratches.
The radio output signal is distorted, too low or
shows interference. • Make sure the antenna is properly connected.
• Make sure the antenna is positioned to receive the best
signal.
• Make sure the antenna is suited to receive the desired
station.
Intermittent radio output , buzz or distorted
radio signal. • This is often due to interference with neon lights, lamps,
engines or electric devices.
This product complies with Directive 89/336/EEC (Electromagnetic Compatibility)
and following amendments 92/31/EEC and 93/68/EEC, according to the following standards:
EN 50082-1:1997, EN 55013:1990, EN 55020:1994
It also complies with Directive 73/23/CEE (Low Voltage)
and following amendment 93/68/EEC, according to the following standard:
EN 60065:1998
Model SOURCE
Features:
FM synthesizer tuner
10 memory presets
CD with mechanical and electronic anti-shock, CD,
CD-R, CD-R/W, MP3, USB MP3 available.
Input:
FM 75 ohm unbalanced antenna terminals
USB port for memory stick
Power Supply: 230V AC 50/60Hz
Power Consumption: 50 VA
Weight: 3,5kg
Dimensions: 482mm*44mm*250mm
Proel S.p.A. pursues a policy of constant research and development and therefore reserves the right to improve its products at any time without prior
notice. REV: 00 / 37-08
