7. MICROPHONE CALL STATION USE
7.1 General call
Press ALL key following TALK key, “chime” function purposes is set. Wait for a commutation
from red to green colour of TALK led indicator effect the microphone call. To end the
announcement release TALK key.
7.2 Zones call.
A- Press the relevant key for zone selection, the linked led lights to evidence the zone
activation. To deactivate the zone re-press the corresponding key then the linked led is
OFF.
B- Press subsequently TALK key the tone “chime” function is set. Wait for the commutation
colour from red to green of the led linked to TALK key, effect the announcement or call. To
end the call release TALK key.
8. TECHNICAL SPECIFICATIONS
MODEL BM16-BM08-BM04-BM01
Microphone polar pattern cardioid
Sensibility 4mV/Pa
Gooseneck length 300 mm
Output level Digital audio
Tone/level control Trimmer to rear panel
S/N Ratio > 100 dB
Frequency range (-3dB) 150Hz - 8KHz
Power supply 12Vdc phantom or local
Dimensions (WxDxH) 232 x 131 x 61 mm
Weight 0.95 Kg
The product is in compliance with Directive 89/336/EEC (Electromagnetic Compatibility)
and following modifications 92/31/EEC and 93/68/EEC, as the following standards:
EN 50082-1:1997, EN 55013:1990, EN 55020:1994
It is also in compliance with Directive 73/23/EEC (Low Voltage)
and following modifications 93/68/EEC, as the following standard:
EN 60065:1998
Proel SpA company pursues a policy of continuous research and development. Proel SpA company reserves the right to modify
product circuitry and appearance at any moment, without prior notice. REV: 01 / 30-08
