Technical Specifications
Model AMIX4Z
Input connectors
LINE: n.8 RCA (4 jack ø 6.3 mm x L\MONO - R)
MIC: n.1 XLR 3 pin female with priority option
Output connectors MASTER: n.4 XLR 3 pin male + n.4 jack ø 6.3 mm
HEADPHONE: n.1 jack ø 6.3 mm TRS
Frequency response 20 Hz - 20 kHz ± 0.5dB
Harmonic Distorsion THD 0.005% @ 1kHz
S/N ratio > 100 dB
Master Gain +10 dB
Input sensitivity/impedance LINE: +22 dBm Max - 20 kΩ balanced/unbalanced
MIC: +4 dBm - 1 kΩ balanced
Output Levels +22 dBm Max
Output impedance LINE: 200 Ω
HEADPHONE: 30 Ω Min
Indicators
CLIP led red
MASTER OUT led bar -30dB/-20dB/0dB/Clip
Power supply power supply adapter included
Current Drain 500 mA
Rack Unities 1U 19” rack standard
Dimensions WxHxD 483x44x200 (in mm.)
Weight 1.70 kg - 3.75 Lbs
The product is in compliance with Directive 89/336/EEC (Electromagnetic Compatibility)
and following modifications 92/31/EEC and 93/68/EEC, as the following standards:
EN 50082-1:1997, EN 55013:1990, EN 55020:1994
it is also in compliance with Directive 73/23/EEC (Low Voltage)
and following modifications 93/68/EEC, as the following standard:
EN 60065:1998
Proel SpA pursue a policy of continuous research and development. Proel SpA reserve the right to modify
product circuitry and appearance at any moment, without prior notice.
