Proel SE8W - Manuale (Pagina 6)

SPECIFICHE TECNICHE
Model SE8 / SE8W
System type 2-way vented enclosure
RMS power 225 W
Peak power 450 W
Nominal impedance 8Ω
Sensitivity 95 dB SPL (2.83V @ 8Ω)
Rated maximum SPL 121dB
Frequency response 63 Hz - 20 kHz
Low frequency device 8” woofer - 2” voice coil
High frequency device 1” compression driver-1” voice coi
Coverage dispersion angle 60°x60° averaged
Crossover frequency
2500 Hz
Input connectors Speakon
Output connectors Speakon linked
Enclosure 15 mm birch plywood with paint finish
Flying points 4xM10 - top, bottom,rear
Monitor taper 45°
Dimensions (mm) W 260 - H 320 - D 280
Weight 10 kg - 22 lbs
Color black / white
