Installation
1. Two holes 102 mm apart should be made where the speaker is to be
installed.
2. Firmly fix the mounting bracket.
3. Select the desired output level by connecting the audio signal line to the
neutral (black) and the positive (coloured) terminals in correspondence
to the required power level:
Caution: Never use the configuration marked “
- “ in the table above
since this may damage the speaker.
Note
You can find the same colour/power correspondence on the
speaker input cable.
PR15PL
brown 670 Ω 15 W
red 1 K Ω 10 W
orange 1,4 K Ω 7 W
grey 3,3 K
Ω 3 W
black neutral
PR30PL / PR30PL
Voltage
colour
100V 70V 50V
brown 83 Ω - - 30 W
red 165
Ω - 30 W 15 W
orange 330 Ω 30 W 15 W 7,5 W
grey 670
Ω 15 W 7,5 W 3,8 W
white 1,3 K Ω 7,5 W 3,8 W 1,9 W
black neutral
