Installation
1. Two holes should be made where the speaker is to be installed, using
the following distances:
Hole distances
(mm)
PR10PL
PR10PLB
PR10AL
PR10ALBI
60
PR20AL
PR20ALBI
120
2. Firmly fix the mounting bracket.
3. Select the desired output level by connecting the audio signal line to the
neutral (blue) and the positive (coloured) terminals in correspondence
to the required power level:
Note
You can find the same colour/power correspondence on the
speaker input cable.
Model
Colour
PR10PL / PR10PLB
PR10AL
PR10ALBI
PR20AL
PR20ALBI
Impedance
Output
power
Impedance
Output
power
red 1 K
Ω 10 W 500
Ω 20 W
yellow 2 K
Ω 5 W 1 K
Ω 10 W
green 4 K
Ω 2,5 W 2 K
Ω 5 W
blue neutral
