Proel BM100 - Manuale (Pagina 8)

If two or more BM100A are connected in parallel, the led indicator is ON status when one
of these BM100A stands is activated.
On rear panel microphone stand two holes for tone and output signal audio level
control are present ( thanks to screwdriver)
fig.4
Operating suggestions
•
If the microphone is placed too close to speaker or its capsule is oriented towards a speaker,
it could generate feedback (Larsen effect). Avoid placing the microphone too close to the
speaker, and avoid orienting its capsule toward the speaker. IF, despite these practises, you
hear feedback, please lower speaker volume.
•
It’s important to keep the anti-pop foam clean; foreign particles on the foam could modify
frequency response. Periodically wash the anti-pop foam using warm water with mild soap,
rinse the foam with clean water, then let the foam dry thoroughly before placing it again on the
microphone.
•
Due to the microphone’s very high sensitivity, be careful the microphone isn’t dropped and
avoid shock, as it could be damaged.
•
In order to maintain sensitivity and performance, avoid exposing the microphone to moisture
or high temperatures.
Model BM100 BM100A
Polar pattern cardioid cardioid
Sensitivity 4mV/Pa 4mV/Pa
Output level Balanced-3mV/600 ohm Unbalanced 1,5V/1Kohm
Frequency response (-3dB) 150 - 12KHz 150 - 12KHz
Gooseneck lengtht (mm) 300 300
dim HxLxP(mm) 50 x 120 x 130 50 x 120 x 130
Weight Kg 0,7Kg
