Proel HPX8000 - Manuale (Pagina 3)

3
Power 8 ohm * 1800 W
Power 4 ohm ** 3200 W
Power 2 ohm ** 3900 W
Power BRIDGE 8 ohm ** 6000 W
Power BRIDGE 4 ohm ** 7200 W
Output Stage Class I
Frequency response (+0/-0.5 dB) 20 Hz - 20 KHz
Input Sensitivity (selectable) 0.775 Vrms (0 dBu) / 1.0 Vrms (0 dBV) / 32 dB (fixed GAIN)
Input Connectors / Impedance XLR M (with XLR F LINK), 20 Kohm (balanced), 10 Kohm (unbalanced)
Output Connectors SPEAKON and Binding Post
Damping Factor > 800
Slew Rate > 20 V/uS
S/N Ratio (unweighted) > 85 dB
THD+N < 0.05%
Controls INPUT LEVEL, INPUT SENSITIVITY, STEREO/BRIDGE/PARALLEL
LED Indicators ON, BRIDGE, SIGNAL, LIMIT, PROTECT, TEMP
Cooling Variable speed DC fan
Protections AC low power, DC, thermal, short circuit, VHF, CLIP limiter
Mains Supply Voltage 230 V~ (±10%) 50/60 Hz or 120V~ (±10%) 50/60 Hz
Maximum Consumption 3200 W
Rated Consumption *** 800 W
Standby Consumption 120 W
Dimensions (W x H x D) 483 x 89 x 451 mm
19" x 3.5" x 17.7" (2U rack)
Weight 15.5 Kg (34.2 lb)
* RMS both channel THD < 1%
** 40 ms burst
*** Rated consumption is measured with pink noise with a crest factor of 12 dB, this can be considered a standard music program.
TECHNICAL SPECIFICATIONS SPECIFICHE TECNICHE
