Technical Specifications
Section
Technical Specifications Connections
MONO INPUT CHANNEL
Mic Input
sensitivity -0 to -60 dB XLR-F, balanced
impedance 2 Kohm
Line Input sensitivity +20 a -40 dB TRS Jack, Bal/Unbalanced
impedance 10 Kohm
EQ HI ±15 dB @ 12KHz shelving
MID ±15 dB @ 100Hz to 8kHz, peaking, Q=1,8
LOW ±15 dB @ 80Hz shelving
STEREO INPUT CHANNEL
Mic Input
sensitivity from 0 to -40dB XLR-F, balanced
impedance 2 Kohm
Line Input sensitivity from +20 to -20dB TRS Jack, Bal/Unbalanced
impedance 10 Kohm
EQ HI ±15 dB @ 12KHz shelving
MID ±15 dB @ 500Hz and 3KHz peaking
LOW ±15 dB @ 80Hz shelving
MASTER SECTION
MASTER, GRP1-2
Nominal output level +4 dBu TRS Jack, Balanced
C. ROOM output Nominal output level +4 dBu TS Jack, Unbalanced
AUX 1 OUT Nominal output level +4 dBu TS Jack, Unbalanced
AUX 2 OUT Nominal output level +4 dBu TS Jack, Unbalanced
AUX 3 OUT Nominal output level +4 dBu TS Jack, Unbalanced
2-TRK OUT Nominal output level 0 dBu Rca Unbalanced
2 TRK IN Nominal input level. -10 dBv Rca Unbalanced
PHONES Minimum load impedance 32 ohm Jack Stereo
Maximum output level (2x) 193 mW
DIGITAL EFFECT PROCESSOR
Preset
HALL, ROOM, VOCAL e PLATE reverbs
STEREO, MONO & TAP DELAYS
CHORUS & FLANGER MODULATIONS
REV + STEREO DELAY, MONO DELAY, CHORUS, FLANGER combinations
16 VARIATIONS FOR EACH PRESET
GENERAL SPECIFICATIONS
Maximum Output Level – All Outputs +22 dBu
Crosstalk @1 KHz > 82 dBu
Signal/Noise ratio - unweighted < -93 dBu
THD + noise at +4dB, 1kHz < 0,008 %
Weight 6.5 Kg
Dimensions (LxAxP) 48.5 x 43.5 x 9 cm
POWER REQUIREMENTS
Mains Supply
Europe 230 V AC (±10 %) 50 / 60 Hz
Consumption 75 VA
Carisch S.p.A. reserves the right to modify products aspect and specifications at any time, without notice.
Please refer www.xxlinside.com for any further detail
Please refer to your XXL Dealer for your country rules about servicing.
©XXL 2013– All rights reserved. Any not-approved copy and use, even partial, of this instruction manual and its texts, it’s
forbidden.
